UP TO 300 BAR
CLW
FLUID END: Nickel-Plated Brass
POWER RATING up to 19 kW
OPERATING PRESSURE up to 200 Bar
FLOW RATE up to 100 l/min
CL
FLUID END: Stainless Steel AISI 303
POWER RATING up to 19 kW
OPERATING PRESSURE up to 200 Bar
FLOW RATE up to 70 l/min
EL – ELR
FLUID END Cast Iron
POWER RATING up to 31,6 kW
OPERATING PRESSURE up to 190 Bar
FLOW RATE up to 164 l/min
ELS
FLUID END Cast Iron
POWER RATING up to 41 kW
OPERATING PRESSURE up to 210 Bar
FLOW RATE up to 164 l/min
EF -EFR
FLUID END Stainless Steel AISI 420
POWER RATING up to 46 kW
OPERATING PRESSURE up to 250 Bar
FLOW RATE up to 183 l/min
ES – ESR
FLUID END Stainless Steel AISI 420
POWER RATING up to 60 kW
OPERATING PRESSURE up to 250 Bar
FLOW RATE up to 220 l/min
SL – SLR
FLUID END Cast Iron
POWER RATING 81 kW
OPERATING PRESSURE up to 300 Bar
FLOW RATE up to 316 l/min
MLR
FLUID END Cast Iron
POWER RATING 118 kW
OPERATING PRESSURE up to 250 Bar
FLOW RATE up to 420 l/min
RLR
FLUID END Cast Iron
POWER RATING 140 kW
OPERATING PRESSURE up to 250 Bar
FLOW RATE up to 480 l/min
280 < 600 BAR
CH
FLUID END Stainless Steel AISI 420
POWER RATING up to 24 kW
OPERATING PRESSURE up to 500 Bar
FLOW RATE up to 31 l/min
ELH – ELHR
FLUID END Stainless Steel AISI 420
POWER RATING 36 kW
OPERATING PRESSURE up to 600 Bar
FLOW RATE up to 70 l/min
EFH
FLUID END Stainless Steel AISI 420
POWER RATING up to 44,9 kW
OPERATING PRESSURE up to 600 Bar
FLOW RATE up to 68,4 l/min
ESH – ESHR
FLUID END Stainless Steel AISI 420
POWER RATING up to 53,8 kW
OPERATING PRESSURE up to 600 Bar
FLOW RATE up to 83,1 l/min
1000 < 1500 BAR
EV – EVR
FLUID END Stainless Steel AISI 630
POWER RATING up to 37,5 kW
OPERATING PRESSURE 1000 Bar
FLOW RATE up to 19 l/min
EFV
FLUID END Stainless Steel AISI 630
POWER RATING up to 47 kW
OPERATING PRESSURE up to 1500 Bar
FLOW RATE up to 24 l/min
ESV – ESVR
